4621033002 Centura Lite 6 HD
Centura Lite 1
Centura Lite 3

Centura Lite – Single Motor

Centura Lite – Single Motor

The solution to CPM therapy provided at home – Kinetec Centura Lite – Single Motor  462103310

For the Rotation Motor Accessory please use the code 4670027414

For the Replacement Patient Pad Kits please use the code US-ITEM00001

Add to wishlist
Contact us for Price

    Description

    The solution to CPM therapy provided at home.

    • Extremely compact & lightweight
    • Essential movements featured
    • Evolution compliant
    • Kinetec Data Capture™ USB technology ready

    Compact design

    The Kinetec Centura Lite™ has been designed to fulfill the requirements for CPM therapy at home. Its exceptional lightweight & compact design makes it the ideal choice for the home environment as well as transportation. Its enhanced, foam-covered chair provides the patient with greater comfort throughout the therapy session.

    Essential movements featured on this modular device

    The Kinetec Centura Lite™ 1 motor allows 2 anatomical movements covering the main pathologies of the shoulder:

    – Abduction/Adduction (20° to 160)
    – Flexion/Extension (20° to 180°)

    The device has been designed with additional modules so the user can upgrade it as required.

    Evolution compliant

    The Kinetec Centura Lite™ is available in different versions to fit with your daily requirement and use. The device has been designed with additional modules so the user can upgrade the product as required.

    Kinetec Data Capture™ USB technology ready

    The Kinetec Centura Lite™ 1 motor remote control features the latest USB technology enabling the use of the Kinetec Data Capture™ software and patient USBs to track patient progress as well as pre-program the entire patient rehabilitation protocol.

    Technical specifications

    Automatically resets the parameters when the movement is changed. This prevents incompatible range of motion to the patient’s condition.

    Load reverse ensures patient safety when excessive force is exerted on the joint.

    Possibility to lock the adjustment of the parameters.

    Precise adjustment of the parameters of the movement.

    Modulation: Allows manual setting of the ROM end-point based on patient tolerance. This mode is generally used at the beginning of the session.

    ROM By-Pass: Used during the session, this mode allows a manual setting based on new patient tolerance, thus offering a real progressive work of the range of motion.

    Force: This security feature allows the patient to reverse, the movement following muscular contraction.

    Pauses: Pauses at movement limits, for improved outcomes.

    2-year full warranty.

    Type BF class II electrical device.

    Speed: 50° to 140° per minute.

    Weight: 297 lbs (135kg)

    Size of the device: Length 22″ (56cm), width 39″ (100cm), height 30″ (76cm) (variable).

    Patient sizing: from 4.6 ft to 6.2 ft (1.4m to 2m).

    User weight: 97lbs (44kg).

    Our Youtube channel features the unboxing and set up of our CPM’s. Click on the link below to see:

    Unit and patient set up
